Product name: Polyester Banner Flag Printing Machine Roll To Roll Type Directly Printer
Description:
- Saer Textile Inkjet Printer: with high resolution, outdoor and indoor applied, designed especially for printing of textile, sublimation banner cloth etc.
- This unit is double 4 color type outdoor and indoor printer, Adopts the Epson 5113 of piezo technology, 3 heads, each head has 1440 nozzles in 8 rows, long using life.
- Using HIWIN mute guide rail. germany IGUS silent drag chain, make your printing environment more quiet.
- Strong Media Feed-in system, for smooth printing on heavy materials, such as textile, sublimation banner cloth and so on.
- X axis and Y axis are using AC serve motors
Advantages:
1.Equipped with the feeding motor Positive and Negative transfer function, taking and feeding constant tension transmission system.
2. The unique print platform design to make the cloth always smooth in the process of printing.
3. Unique filtering lampblack system, make the picture very clean.
4. Taking up and feeding roller are inflatable roller.
5. Taking up and feeding fabric are smoothly
Specifications:
1. Constant temperature heating box rapidly heating, good leakproofness ensure the temperature constant
2. Green smoke extraction filtration system filter and sublimation smoke efficiently, keep the environment clean
3. open ink-supply system Compatible with many brands of sublimation ink, easily to control the printing cost.
| Product Parameter |
| Model type | CSR3200 |
| Print head | 3 pieces Epson 4720 |
| Ink | Sublimation ink, pigment ink |
| Number of nozzles | (400 nozzles*8lines)*3head |
| Color | Dual CMYK |
| Print head high | 1.5mm/6mm (adjustable) |
| Ink supply mode | Continuous ink supply |
| Max materials width | 3300mm |
| Max printing width | 3200mm |
| Printing resolution and speed | Resolution(dpi) speed |
| 360*1800dpi(3 pass) 65m2/h |
| |
| 720*1220dpi(4 pass) 45m2/h |
| |
| 720*1800dpi(6 pass) 35m2/h |
| Roll outer diameter | 3 inch |
| Maximum weight for roll material | 100kg |
| Interface | USB2.0 |
| RAM | 128M |
| Printer Power | AC100-120V/AC220-240V(adjustive) 50/60HZ |
| Power | Heater 3.5kw |
| Printer 100w |
| Temperature | 30-32℃ |
| Humidity | 40-60%(Non-condensing) |
Competitive Advantage:
NEW technology on Epson 4720 , less ink consumption
High Resolution up to 1440dpi
High Printing speed up to 45sqm/h
High working stability, industrial performance
High Productivity
Long Using Life
High Yield
Support three Epson 4720 print head
Perfect Color Presentation
Application industry:
1), personality print: such as shops, cell phone decoration shop, personality gift shop.
2), advertising industry: indoor and outdoor advertising.
3), products proofing: all kinds of traditional printing sample production.
4), studio: digital image production.
5), clothing industry: sample print or character pattern of color printing.
