Digital Inkjet Roll To Roll Textile Printing Machine
Contents:
One all-in-one printer (print and heat together,can not seperate & One filter fan for collect waste air
Usage:
Serve solutions for small production, sample making ,designer ideas and training areas .
Can be used indoor and outdoor,friendly to environment.
Product Feature
1. This Dye Sublimation Textile Printer Machine For POLYESTER and Full cotton . It can Direct Printing on Sublimation Polyester. It is also can print full cotton. If you print cotton fabirc . this machine have to use Pigment Ink.
2. It Adopt Newsest Epson DX5 Printhead With High Precison.
3. This Textile Printer Machine For Flag Use Dye Sublimation Ink . No Smell, no pollute.
4. This machine with print and heat function . save cost and place.
5. It is direct print image into Fabric .
Product Technical Data
| Product Parameter |
| Model | CSR 2200 |
| Print head | Piezo texhnology,Epson 5th printer head |
| Ink | Sublimation ink,Reactive ink,Reactive ink |
| Color mode | 4*4 color |
| Nozzles | (180nozzles*8lines)* 2heads |
| Print head higher | Adjustable |
| Ink supply mode | Continuous ink supply |
| Max meterials width | 2200mm |
| Max printing width | 2100mm |
| Printing resolution and speed | Resolution | speed |
| 720*360dpi 2pass | 40sqm/h |
| 360*1080dpi 3pass | 32sqm/h |
| 720*720dpi 4pass | 22sqm/h |
| 720*1080dpi 6pass | 18sqm/h |
| | | | | 720*1440dpi 8pass | 12sqm/h |
| Roll owter diameter | 3 Inch |
| Max weight for roll materials | 100kg |
| Interface | USB 2.0/HIUSB |
| RAM | 128M |
| Printer with heater power | AC220V 50/60Hz |
| Power consumtion | 6.5KW |
| Environment | Temperature:20-32℃ |
| Humidity:40-60℃(Non-condensing) |
| weight | 780kg |
Specifications:
Save Money No need to use transfer paper
Save Time No need to perform heat transfer step
Save Space No need to keep a workplace for a heat transfer
Product Features:
- Saer Textile Inkjet Printer: with high resolution, outdoor and indoor applied, designed especially for printing of textile, sublimation banner cloth etc
- This unit is double 4 color type outdoor and indoor printer, Adopts the Epson 7th Generation of piezo technology, two heads, each head has 1440 nozzles in 8 rows, long using life.
- Using HIWIN mute guide rail. germany IGUS silent drag chain, make your printing environment more quiter.
- Strong Media Feed-in system, for smooth printing on heavy materials, such as textile, sublimation banner cloth and so on.
- X axis and Y axis are using AC serve motors
characteristics:
1. Low cost: About 2 degree electricity cost per hour with non-stop running
2. High productivity:40m2 / hour of the speed
3. Dye Sublimation system: print onto fabric with sublimation ink.
4. Directly print on textile: no need any transfer paper.
5. Good after sales service: 1 year maintenance period.
Produtc Service :
1. This machine has One year warranty .
2. We Support Oversea technical service and with all life techincal support.
How To Order:
Inquriy-------Quotation-------Order-------Production-------Quality Control-------Packing-------Shipping-------Delivery
